Installation | 26
MHTC Reflow Electrical
Figure 24: MHTC Reflow Primary Power and Hydraulic Unit Wiring
MHB Electrical
Connect primary power as shown above. For MHB models wiring must be installed from the
control box to each staging valve.
High voltage
terminal block
Install wiring (by others)
between control panel
and hydraulic unit terminal
blocks.
Connect corresponding
numbered terminals.
Hydraulic Unit
Control Panel
