PCI-DAS6071 User's Guide Installing the PCI-DAS6071
10
When using a sinusoidal input signal for the Analog Output External Reference, the -3dB multiplying
bandwidth of both VDAC0 and VDAC1 is approximately 250 kHz. It should also be noted that the AC
feedthrough of both VDAC0 and VDAC1 increases with input frequency and may be as much as -45 dB for a
1 MHz sinusoidal External Reference input.
Signal connections
SCSI connector
The table below lists the board connectors, applicable cables and compatible accessory boards.
Board connectors, cables, accessory equipment
Connector type Shielded SCSI 100 D-Type
Compatible cables C100HD50-x, unshielded ribbon cable. x = 3 or 6 feet
(see Figure 1 on page 13)
C100MMS-x, shielded round cable. x = 1, 2, or 3 meters
(see Figure 2)
Compatible accessory products
(with the C100HD50-x cable)
ISO-RACK16/P
ISO-DA02/P
BNC-16SE
BNC-16DI
CIO-MINI50
CIO-TERM100
SCB-50
Compatible accessory products
(with the C100MMS-x cable) SCB-100
