CB-7000 DIO Manual
7
6
5
4
3
2
1
0
1
*
2
*
0
0
0
3
*
Type Setting (TT)
Type = 40 for DIO mode
Data Format Setting (FF)
*1: Counter Update Direction: 0=Falling Edge, 1=Rising Edge
*2: Checksum Bit: 0=Disable, 1=Enable
*3: 7050 = 0 (Bit[2.1.0] = 000), 7060 = 1 (Bit[2.1.0] = 001)
7052 = 2 (Bit[2.1.0] = 010), 7053 = 3 (Bit[2.1.0] = 011)
Read Digital Input/Output Data Format
Data of $AA6,$AA4,$AALS: (First Data)(Second Data)00
Data of @AA: (First Data)(Second Data)
