24
CB-7000 DIO Manual
e
d
o
C
3
0
4
0
5
0
6
0
7
0
8
0
9
0
A
0
e
t
a
r
d
u
a
B
0
0
2
1
0
0
4
2
0
0
8
4
0
0
6
9
0
0
2
9
1
0
0
4
8
3
0
0
6
7
5
0
0
2
5
1
1
1.6 Quick Start
Refer to “CBCOM Series Network Setup and Quick
Start Manual” and “Getting Started” for details.
1.7 Default Setting
Default setting for CB-7000 DIO modules:
l
Address: 01
l
Baud rate: 9600 bps
l
Type: Type 40 for DIO mode
l
Checksum Disable
l
CB-7043/43D jumper setting at INIT*
l
CB-7053/53D jumper setting at INIT*
1.8 Jumper Setting
CB-7043/43D: Jumper J3 for select the pin INIT*/DO15
Select DO15
Select INIT*
(default)
CB-7053/53D: Jumper J1 for select the pin INIT*/DI15
Select DI15
Select INIT*
(default)
1.9 Configuration Tables
Configuration Table of CB-7000 DIO modules
Baud rate Setting (CC)
