BOX HEIGHT WIRING VOLUME WIRING VOLUME WIRING VOLUME WIRING VOLUME WIRING VOLUME
(with Divider) (with Divider)
Inches [mm] Cu. Inches [mm] Cu. Inches [mm] Cu. Inches [mm] Cu. Inches [mm] Cu. Inches [mm]
6 [152.0] 65.0 [1065.0] 15.0 [738.0] 27.9 [457.0] 47.9 [784.0] 20.0 [327.0]
5 1/2 [140.0] 58.0 [950.0] 39.3 [644.0] 22.2 [364.0] 40.9 [670.0] 18.7 [306.0]
5 [127.0] 51.0 [835.0] 33.6 [551.0] 16.5 [270.0] 33.9 [554.0] 17.4 [284.0]
4 1/2 [114.0] 44.0 [720.0] 27.9 [457.0] 10.8 [177.0] 26.9 [440.0] 16.1 [263.0]
4 [102.0] 37.0 [605.0] 22.2 [364.0] 14.8 [241.0]
3 1/2 [89.0] 30.0 [490.0] 16.5 [270.0] 13.5 [220.0]
3 [76.0] 23.0 [377.0] 10.8 [177.0] 12.2 [200.0]
Volume Capacities for Ratchet-Pro PVC Floor Box
To calculate the total box
volume, use displacement
of the largest uncut
section remaining. Single Service 895 &
896 Activations
Dual Service 895DCC
Activations
Dual Service 881TC,
881RC4ATC, 897CTC,
897CFFTC & 899CTC
Activations
Single Service
881CM2TC
Activations
Single Service
881AV3, 881AMD8,
8814FF & 897CFF
Activations
CAUTION:
Do not use in concrete
pours less than 4 1/2"
[114mm] CAUTION:
Do not use in concrete
pours less than 4 1/2"
[114mm]
