58

Set

tings

Basic Settings

User Tone Control

The User Tone Control option allows fi ner control over the instrument’s sound character, allowing the volume of

four frequency bands to be adjusted individually. It is also possible to adjust the frequency range of the mid-low

and mid-high frequency bands.

User Tone Control setting

No.

User Tone Control

Description

1

Low

Adjusts the volume of the low range frequency band (20 - 100 Hz).

2

Mid-low Frequency

Adjusts the frequency of the mid-low band (355 - 1000 Hz).

Mid-low dB

Adjusts the volume of the mid-low range frequency band.

3

Mid-high Frequency

Adjusts the frequency of the mid-high band (1120 - 3150 Hz).

Mid-high dB

Adjusts the volume of the mid-high range frequency band.

4

High

Adjusts the high range frequency band (5000 - 20000 Hz).

1. Selecting the User Tone Control setting

After selecting the Tone Control setting (page 57):

Press the

 or  buttons to select the User Tone Control type,

then press the FUNCTION button (EDIT).

The User Tone Control screen will be shown in the LCD display.

2. Selecting and adjusting the User Tone Control settings

Press the

 or  buttons to select the User Tone Control

setting.

Press the

 or  buttons to increase or decrease the value of

the selected User Tone Control setting.

* Each User Tone Control band can be adjusted within the range of

–6 dB - +6 dB.

* To reset the User Tone Control setting to the default type, press the

FUNCTION button (RESET).

* Any changes made to the User Tone Control setting will remain until

the power is turned off .

3. Exiting the User Tone Control setting

Press the FUNCTION button (BACK) to exit the User Tone

Control setting and return to the Tone Control setting.
