Mini-XLR
Picture Pin Signal
1 GND
2 Data +
1 3 2
3 Data –
Pos: 101 /806-IHSE/Technische Daten/Pinbelegungen/TOSLINK @ 5\mod_1291129073656_6.doc @ 44958 @ @ 1
TOSLINK
Picture Diode Signal
1
1 Data IN / OUT
Pos: 102 /806-IHSE/Technische Daten/Stromversorgung/482-xx @ 10\mod_1385652314288_6.doc @ 103285 @ 2 @ 1
7.5 Power Supply
AC Power Supply
Model Max. Current Max. Voltage Frequency
474-BODY2N 700 mA max. 100-240 V 50/60 Hz
474-BODY6R 1,400 mA max. 100-240 V 47-63 Hz
474-BODY6BP 800 mA max. 100-240 V 50/60 Hz
474-BODY21/4U 4,000 mA max. 2x 100-240 V 50/60 Hz
DC Power Supply
Model Max. Current Max. Voltage
474-BODY2/2R 3,000 mA 5 VDC
474-BODY2N 5,000 mA 5 VDC
474-BODY4/4R 5,000 mA 5 VDC
474-BODY6R 8,000 mA 5 VDC
