3.6.6 21-fold Vario Chassis 474-BODY21R
CPU and CON Unit
1
Rear View
1
Slots for modules #1 - #21
1
2
3
4
Front View
1
Connect to power supply 2
2
Locking for power supply 2 (redundancy)
3
Locking for power supply 1 (standard)
4
Connect to power supply 1
