Draco KVM Extender
20
2013-12-06
Pos: 18 /806-IHSE/Beschreibung/Geräteansichten/474-xx/Typ L- / R474-BDHC / -B2HC @ 9\mod_1373959428603_6.doc @ 77301 @ 3 @ 1
3.6.7 Model L- / R474-BDHC / -B2HC
CPU Module
CON Module
1
2
3
4
1
2
4
3
Rear View
Rear View
1 Service
port
2
Connect to interconnect cable
3
To CPU: USB-HID
4
To CPU: DMS-59
1 Service
port
2
Connect to interconnect cable
3
Connect to USB-HID devices
4
Connect to monitor(s) (DMS-59)
Pos: 19 /806-IHSE/Beschreibung/Geräteansichten/474-xx/Typ L- / R474-BDHS/X / -B2HS/X @ 9\mod_1373959653960_6.doc @ 77322 @ 3 @ 1
3.6.8 Model L- / R474-BDHS/X / -B2HS/X
CPU Module
CON Module
1
2
3
4
1
2
4
3
Rear View
Rear View
1 Service
port
2
Connect to interconnect cable
3
To CPU: USB-HID
4
To CPU: DMS-59
1 Service
port
2
Connect to interconnect cable
3
Connect to USB-HID devices
4
Connect to monitor(s) (DMS-59)
