3.6.5 6-fold Vario Chassis 474-BODY6BP
CPU and CON Unit
1
2
3
Front View
1
Connect to power supply 1
2
Connect to power supply 2 (redundancy)
3 Grounding
3
4
5
1
2
6
Rear View
1
Slot for modules #5
2
Slot for modules #3
3
Slot for modules #1
4
Slot for modules #6
5
Slot for modules #4
6
Slot for modules #2
