Page 24: Draco kvm extender 24
Draco KVM Extender
24
2013-12-06
3.6.17 Model L- / R474-BDX
CPU Module
CON Module
1
3
2
1
3
2
Rear View
Rear View
1
S/PDIF input (RCA)
2
AES/EBU input (Mini-XLR)
3
S/PDIF input (TOSLINK)
1
S/PDIF output (RCA)
2
AES/EBU output (Mini-XLR)
3
S/PDIF output (TOSLINK)
