IHSE USA 482 Series Draco vario Dual- Head - Manual (Page 54)

Draco KVM Extender
54
2013-12-06
Connection Format DTE (Data Terminal Equipment)
Speed Up to 115,200 Baud
Data Format Format independent
Data Transmission  RxD (Receive Data)
 TxD (Transmit Data)
Traffic Control The following signals are transmitted
(hardware handshake):

RTS (Request To Send)
 CTS (Clear To Send)
 DTR (Data Terminal Ready)
 DSR (Data Set Ready)
Pos: 73 /806-IHSE/Technische Daten/Schnittstellen/Serielle Schnittstelle RS422 @ 9\mod_1362475591209_6.doc @ 71309 @ 3 @ 1
7.1.9 Serial Interface RS422
KVM Extenders with a serial interface RS422 (D-Sub 9) support a
differential full duplex transmission up to a Baud rate of 115,200 Baud.
The CPU unit is designed as controlling device and so can be for example
connected directly to video or media servers.
The CON unit is designed as a controlled device and so can be connected
directly to remote controllers.
Connection Format Sony Standard
Speed Up to 115,200 Baud
Data Format Format independent
Data Transmission  Rx + (Receive Data)
 Rx – (Receive Data)
 Tx + (Transmit Data)
 Tx – (Transmit Data)
