Draco KVM Extender
56
2013-12-06
Specifications Analog Audio USB 2.0
Transmission Format Digitized virtually CD quality audio, 16 bit
(8, 11.025, 16, 22.05, 32, 44.1, 48 KHz)
Signal Level Line-Level (5 Volt Pk-Pk maximum)
Input Impedance 20 KOhm
Connections CPU Unit 1x USB type B female connector
Connections CON Unit 2x 3.5 mm stereo jack plug
(audio in & audio out)
Pos: 75 /806-IHSE/Technische Daten/Schnittstellen/474-xx (Digital Audio-Schnittstellen) @ 6\mod_1304585776832_6.doc @ 51309 @ 3 @ 1
7.1.11 Digital Audio Interface
The digital audio option supports the unidirectional transmission of digital
audio data.
Up to three sources can be connected to the CPU Unit. The active source
is transmitted. If several sources are active, the XLR signal takes priority,
otherwise the first active signal.
The three connectors on the CON Unit all concurrently provide digital
audio.
KVM Extender with digital audio option include an inbuilt sample rate
converter that allows to provide predefined sample frequencies at the
output of the CON unit.
The user can set directly the following parameters by using a configuration
file:
 Activate or deactivate sample rate converter in the Config.txt file on
the flash drive of the KVM Extender.
 If the sample rate converter is activated, the following characteristics
are valid:
140 dB dynamic range and -120 dB total harmonic distortion + noise.
 Set sample frequency of the sample rate converter by writing the
parameter in a new line. The following sample frequencies are
available:
– 32.0 kHz (write SRC32000 in Config.txt file of the CPU unit)
– 44.1 kHz (write SRC44100 in Config.txt file of the CPU unit)
– 48.0 kHz (write SRC48000 in Config.txt file of the CPU unit)
– 96.0 kHz (write SRC96000 in Config.txt file of the CPU unit)
