Specifications
2013-12-06
61
7.4 Connector Pinouts
Pos: 87 /806-IHSE/Technische Daten/Pinbelegungen/482-xx/Buchse DMS-59 Dual-Link @ 10\mod_1385652060067_6.doc @ 103262 @ @ 1
Connector DMS-59 Dual-Link
1-15
16-30
31-45
46-60
Pin Signal Pin Signal Pin Signal
1 GND 21 RX5_U 41 GND
2 n.c. 22 GND 42 GND
3 n.c. 23 n.c. 43 GND
4 GND 24 GND 44 BRXC_N
5 5V DVI 25 RX2_P 45 BRXC_P
6 DDC SCL 26 RX2_N 46 GND
7 DDC SDA 27 RX1_P 47 n.c.
8 GND 28 RX1_N 48 n.c.
9 BDDC SDA 29 RX0_P 49 GND
10 BDDC SCL 30 RX0_N 50 n.c.
11 B5V DVI 31 RXC_P 51 n.c.
12 GND 32 RXC_N 52 GND
13 n.c. 33 GND 53 n.c.
14 n.c. 34 GND 54 GND
15 GND 35 GND 55 n.c.
16 RX3_P 36 HPD 56 n.c.
17 RX3_N 37 n.c. 57 GND
18 RX4_P 38 n.c 58 n.c.
19 RX4_N 39 n.c. 59 n.c.
20 RX5_P 40 BHPDT 60 GND
