Draco KVM Extender
12
2013-12-06
Model Description
474-BODY6R Empty chassis for up to 6 boards, 1x internal power
supply unit, preparation for redundancy for a second
power supply unit (external)
474-
BODY6BP Empty chassis for up to 6 boards, active backplane, 2x
internal power supply unit (redundancy)
474-
BODY21/4U Empty chassis for up to 21 boards, 1x internal power
supply unit, preparation for redundancy for a second
power supply unit (internal)
3.3.3 KVM Extender Modules
Model Description
L482-BDHx
R482-BDHx
Single-Head module for 1x DVI-D Dual Link
(up to 2560x1600), 2x USB-HID
L482-BDHxR
R482-BDHxR Single-Head module for 1x DVI-D Dual Link
(up to 2560x1600), 2x USB-HID and redundant
connector for interconnect cables
L482-B2Hx
R482-B2Hx
Dual-Head module for 2x DVI-D Single Link
(up to 1920x1200), 2x USB-HID
L482-B2HxR
R482-B2HxR Dual-Head module for 2x DVI-D Single Link
(up to 1920x1200), 2x USB-HID and redundant
connector for interconnect cables
3.3.4 Upgrade Modules
Model Description
L474-BXH
R474-BXH
Upgrade module with 2x USB-HID
L474-BXE
R474-BXE
Upgrade module with 2x USB 2.0
L474-BAX
R474-BAX
Upgrade module with Analog Audio / Serial
(bidirectional)
L474-BAP
R474-BAP
Upgrade module with Analog Audio / Serial
(bidirectional) and PS/2
L474-BSX
R474-BSX
Upgrade module with serial connector (RS422)
