Parts List
HPR800XD Auto Gas –
806500
6-23
Recommended spare parts
Power supply
Part
Number
Description
Designator
qty.
003142
Relay: 120 volt, double pole, double throw
K1
1
129633
Green power lamp assembly
1
129792
Chopper assembly
CH1, CH2, CH3, CH4
1
127039
6" fan: 230 CFM, 115 VAC 50-60 HZ
1
027079
10" fan: 450-550 CFM, 120 VAC 50-60 HZ
1
003149
Relay: Pilot arc, 120 VAC
CR1
1
229213
PCB: I/O
1
003218*
Contactor
CON1
1
003233**
Contactor
CON1
1
109004
Current sensor: Hall 100 amp, 4 volt
CS1, CS2, CS3, CS4
1
229238
Start circuit assembly
PCB1
1
008709*
Fuse: 20 amp, 500 volt
F1, F2
2
108847**
Fuse: 7.5 amp, 600 volt
F1, F2
2
141030
PCB: Control (Primary power supply)
PCB3
1
141144
PCB: Control (Secondary power supply)
PCB3
1
041802
PCB: Power distribution
PCB2
1
108028
Fuse: 3 amp, 250 volt
F5, F6, F7
3
108075
Fuse: 6.3 amp, 250 volt (slow-blow)
F1, F2, F3
3
108709
Fuse: 10 amp, 250 volt
F4
1
141027
PCB: Pump motor drive
PCB7
1
229340
Snubber board
1
229360
Contactor: 500 amp DC 120 VAC COIL
Con2, Con3
2
* 200/208, 220 and 240 volt power supplies
** 380, 400, 440, 480 and 600 volt power supplies
chiller interface console
Part
Number
Description
Designator
qty.
041897
PCB: Console power distribution
1
008756
Fuse: 5 amp, 250 volt (slow-blow)
F1
1
027634
Filter housing (on the rear panel of the cooler)
1
027664
Filter
element
1
229235
Flow sensor
FS1
1
006113
Check valve: 3/8" FPT
1
229345
Solenoid valve
1
141033
PCB: Cooler sensor
1
229224
Temperature sensor
1
