Appendix parts list – Harken 7415.15S MKIV Hydraulic Jib Reefing & Furling User Manual
Page 34
34
MKIV Hydraulic Unit 5
Appendix
Parts List
H-55842
HFS1107
1
1
2
1
2
3
4
5
2
1
6
7
8
9
No.
Description
Order
Part No.
Torque Tube Foil Clamp
1
H-55842
Torque Tube Screws M8 X 125 mm SHCS
4
HFS1107
Red Ring
1
B28169
Lower Unit
1
7415.15BASE
1 Smalley Ring
1
H-53073
2 Tack Swivel Top Washer
1
H-53072
3
1
/
2
" Torlon Ball
28
HBB21
4 Tack Swivel Body
1
H-53069
5
1
/
2
" Delrin Ball
28
HBB22
6 Tack Swivel Lower Washer
1
H-53071
1
2
4
5
6
2
7415.15BASE
B28169
3
No.
Description
Order
Part No.
Toggle Assembly 1
1
/
8
"
1
7415.25 1 1/8
1 Toggle Plate Screws M5 X 16 mm SHCS
8
HFS982
2 Toggle Plate
2
H-51261
3 Toggle Housing Insulator
1
H-53089
4 Cross Pin 1
1
/
8
"
1
H-51605
5 Toggle Housing 1
1
/
8
"
1
H-53087
6 Toggle Housing Screws M10 X 90 mm SHCS
6
HFS1259
7 Cotter Pin
3
/
16
" X 2"
1
HFG743
8 Clevis Pin 1
1
/
8
"
1
H-45436
9 Jaw Jaw Toggle 1
1
/
8
"
1
H-45428
Toggle Assembly 1
1
/
4
"
1
7415.25 1 1/4
1 Toggle Plate Screws M5 X 16 mm SHCS
8
HFS982
2 Toggle Plate
2
H-51261
3 Toggle Housing Insulator
1
H-53089
4 Cross Pin 1
1
/
4
"
1
H-53094
5 Toggle Housing 1
1
/
4
"
1
H-53088
6 Toggle Housing Screws M10 X 90 mm SHCS
6
HFS1259
7 Cotter Pin
1
/
4
" X 2.5"
1
H-46623
8 Clevis Pin 1
1
/
4
"
1
H-52870
9 Jaw Jaw Toggle 1
1
/
4
"
1
H-52864
