MKIV Hydraulic Unit 5 17
Assembly Foils/Connectors
Insert connector into foil and put red
Loctite ® on foil screw holes.
Tip: In cooler weather, keep sealed
adhesive in pocket to keep warm. Use
instructions below to fill injector less
than half way; you will only use a small
amount of adhesive. Refill if needed
but do not keep open sealant for long
periods. Use adhesive within 3 hours.
Use cap of adhesive to break seal. Remove
injector tip cap and plunger. Hold injector
at an angle with applicator tip facing down.
Squeeze adhesive into tube so lower half
of injector is full as shown. Keep tip free
of sealant to let air inside.
Adhesive in
lower half
Assembly Loading Injector with Adhesive
Red Loctite ®
