Appendix toggle dimensions – Harken 7415.15S MKIV Hydraulic Jib Reefing & Furling User Manual
Page 32
32
MKIV Hydraulic Unit 5
A
B
C
D
E
F
G
H
Toggle
in
mm
in
mm
in
mm
in
mm
in
mm
in
mm
in
mm
in
mm
Standard Toggles
7415.25 1 1/8
3.614
91.8
2.700
68.6
1.507
38.3
1.122
28.5
1.210
30.7
2.524
64.1
0.657
16.7
3.014
76.6
7415.25 1 1/4
4.291
109.0
3.134
79.6
1.507
38.3
1.248
31.7
1.312
33.3
2.528
64.2
0.608
15.4
3.014
76.6
Cylinders with Toggles
7415.26 1 1/8
6.677
169.6
2.700
68.6
1.507
38.3
1.122
28.5
1.210
30.7
2.524
64.1
0.657
16.7
3.014
76.6
7415.26 1 1/4
7.354
186.8
3.134
79.6
1.507
38.3
1.248
31.7
1.312
33.3
2.528
64.2
0.608
15.4
3.014
76.6
A
I
J
K
L Radius
L Diameter
M Radius
M Diameter
N
O
Toggle
in
mm
in
mm
in
mm
in
mm
in
mm
in
mm
in
mm
in
mm
in
mm
Standard Toggles
741525 1 1/8
1.125
28.6
1.210
30.7
1.639
41.6
1.891
48.0
3.781
96.0
1.838
46.7
3.676
93.4
1.412
35.9
1.77
45.0
7415.25 1 1/4
1.248
31.7
1.312
33.3
1.796
45.6
1.891
48.0
3.781
96.0
1.838
46.7
3.676
93.4
Cylinders with Toggles
7415.26 1 1/8
1.125
28.6
1.188
30.2
1.653
39.7
—
—
—
—
1.45
36.8
2.9
73.7
7415.26 1 1/4
1.248
31.7
1.312
33.3
1.688
42.9
—
—
—
—
1.45
36.8
2.9
73.7
G
E
F
B
A
C
H
J
I
K
M r
L r
L d
J
I
K
M D
M r
Appendix
Toggle Dimensions
Cylinder
with Toggles
Standard Toggles
Cylinders with Toggles
N
O
Rotational circle used for
figuring rod splice diameter
Maximum Ø to
pass terminals
D
