Assembly
Top Foil
Cut out template at right. Line up template
with top of foil and scribed line. Tape in
place. Use center punch to mark holes.
Check center punch marks to confirm
(see chart below).
Lay top foil in line with others. Slide stay
into top foil and down line of foils or slide
each foil up stay.
MKIV Unit 2E, 3E
15
Foil
To
p
!
1
3
/
8
" (35mm)
3
/
8
" (10mm)
Unit 3
Foil
To
p
1
3
/
16
" (30 mm)
3
/
8
" (10 mm)
!
Unit 2
Unit
Center Punch Marks
2E
3
/
8
" (10 mm)
1
3
/
16
" (30 mm)
3E
3
/
8
" (10 mm)
1
3
/
8
" (35 mm)
Drill two (2) holes for trim cap. See chart
below for correct drill size
Unit
Drill Ø
2
5/32" (4 mm)
3 (3/4, 7/8)
5/32" (4 mm)
