Installation on an Underground Tank - Direct Mount
Installation
3 – Installation
Installation on an Underground Tank - Direct Mount
1 - Install-a-Socket, screw into 2
2 - Coupling, 2” NPT
3 - Standard pipe, 2” x 1016mm. Screw into 2 and 6
4 - Suction pipe, 1” NPT. Screw into bottom of 1
5 - Concrete pad
6 - Tank Flange
7 - Suction tube must be at a minimum distance of 100mm from
the bottom of the tank.
