MDE-4299B CFN Series Profit Point PLUS Installation Manual · March 2007 Page 25
System Components Wiring Diagrams System Components Wiring
Figure 4-4: System Components Wiring Diagram - SCIII/SCIII PLUS/POS WS (Part 1 of 2)
AC Surge Protector
Outlet Strip
Provides power for
SCIII / POS WS,
and all equipment
directly connected to
the SCIII / POS WS
Provide enough outlets
for the CFN equipment
at the site
Conditioned Outlets
Optional Power
Conditioner
Power Directly
From Breaker
(Unconditioned)
Unconditioned Outlet
Unconditioned Outlet
Breaker
AC Ground
H
N
G
H
N
POS
D-Box
Power Supply
Cash Drawer
RS-485 Junction
Box
Receipt
Printer
1 2 4 3 5
TB inside
Junction Box
4
1
Ground
AC
Ground
Telephone
Jack
Whenever you see this symbol on the end of a power
cord, ensure that you plug that power cord into an AC
Surge Protector Outlet Strip.
Modem
Cable Shield
Legend:
PIN Pad
Customer Display
Scanner
See Note.
Note: 4-port Fan-out Cable is supplied with Profit Point PLUS console.
S1 - to Serial 3 on POS D-Box
S2 - to Standalone Receipt Printer S3 - to POS keyboard (or not used)
S4 - not used (or to POS keyboard)
This port may be used
to connect to an
optional current loop
interface
Serial 2
Serial 3
Power
8’ Modular Cable
(supplied by Gasboy)
RS-232 Cable
(comes with PIN
Pad)
RS-232
Cable
RS-485 Modular Cable
(supplied by Gasboy)
Phone Cable
(supplied with Modem)
S1
S4
Cable Supplied
with Keyboard
Note: The USB ports on the CPU tower are not active
and should not be used.
