MDE-4299B CFN Series Profit Point PLUS Installation Manual · March 2007 Page 17
AC Surge Protector Outlet Strip (Profit Point PLUS and Accessories Only) System Layout
AC Surge Protector Outlet Strip (Profit Point PLUS and
Accessories Only)
Description
The AC Surge Protector Outlet Strip helps protect the Profit Point PLUS console and any
equipment directly connected to the Profit Point PLUS system (receipt printer, RS-485 to RS-
232 converter, POS D-Box, and possibly a scanner) from line surges while filtering away
Electromagnetic Interference (EMI)/Radio Frequency Interference (RFI) noise. Depending on
your configuration (number of workstations), you may need more than one outlet strip.
Location
The AC Surge Protector Outlet Strip should be located within 6 feet of the Profit Point PLUS
system and plugged into an unconditioned outlet. It must be located in an area protected from
direct contact with the weather. Do not install over a hazardous location.
Conduit Requirements
The conduit requirements for the Profit Point PLUS system are the same as those for the CFN
system as a whole. Refer to the appropriate Site Controller Installation Manual for conduit
requirements and layout guidelines and restrictions. Pay special attention to the conduit layout
when installing remote Profit Point PLUS consoles.
