MDE-4487C Atlas™ Dispenser Vapor Recovery Kit (M06184K00X) Installation Instructions · September 2008 Page 7
Installing the M06184K00X Vapor Recovery Kit
3 Screw the elbow onto the vapor pipe which goes to the underground tank. Tighten the elbow
and turn in position to receive the nipple coming from the Splitter.
4 Screw the splitter and pipe into the elbow. Tighten and leave the splitter in the position with
threaded ports facing up, as shown in
Figure 2 on page 6 , and align screw holes.
5 Bolt the splitter to the dispenser wall using four 5/16”- 18 x 1” screws and nuts.
Assembling and Installing Product Jumper Hose
The following parts are required to assemble and install the Product Jumper Hose:
• 064560 - 3/4 inch swivel (item 11 )
• HHS6X014BKX1 - 3/4 inch HW hose (item 15 )
• K02297 - 3/4 inch to 1 inch bushing (item 16 )
Use Pipe compound (UL-approved gas and oil-resistant) on all pipe threads.
IMPORTANT INFORMATION
1 Mount the 3/4 inch to 1 inch bushing (item 16 ) in the dispenser outlet (see Figure 3 on page 8 ).
2 Mount the 3/4 inch swivel (item 11 ) on the 3/4 inch HW hose (item 15 ).
3 Connect the fixed end of the 3/4 inch HW hose to the bushing in the dispenser outlet and the
end (with swivel mounted) to the splitter port (item
14 ) labeled FUEL.
