15

102588

23

102445-01

Piezo Ignitor

1

24

078978-03

Sleeve Cap

1

25

099598-04AA

Base

1

26

100397-01

Lock Washer, #4

4

27

099202-02

Steel Rivet, 1/8"

1

28

098835-01

Valve Nut

1

29

099460-01

Hex Cap

1

30

NPF-3C

Nut (Spacer)

2

31

WLE-2BL

Lock Washer, #8

1

32

M50104-01

Bushing, Shorty

1

33

099157-01

Rivet, Aluminium

1

34

099125-10

Terminal Board

1

35

M50400

Strain Relief Bushing

1

36

097545-01

Power Cord

1

37

102559-01

Adapter, 1/4 x 1/4

1

38

102957-01

Valve, Solenoid

1

39

097809-01

Male Fitting

1

40

100596-01AB

Guard, Wire

1

41

102334-01

Nut, Pal

1

42

100594-01AA

Cover

1

43

101520-01

Strain Relief Bushing

1

44

102861-01

Bushing Nut

1

45

M16841-62

Wire Assembly

1

PARTS AVAILABLE - NOT SHOWN

097647-03

Tradename Decal

2

100400-04

General Information Decal

1

100404-04

Operation Decal

1

100399-01

Regulator & Hose Assy.

1

100168-02

Electrical Decal

1

PARTS LIST

KEY

PART

NO.

NUMBER

DESCRIPTION

QTY.

SPECIFICATIONS

Model

BLP35E

Electrical Input

220/240 volt, 50 hertz, 55 watts IP21

Maximum Input, net

10.3 KW at 27 millibar

Regulator Output

27 millibar

Burner Rate

10.3 KW, 796 g/hr

Supply Pressure (min.)

2 bar

Ventilation

260 cm

2

Room Size

103 cubic meters

Air Delivery Class

Type A

Temperature Range for Heater Operation

-29° C to 29° C*

* When running heater in temperatures above 29° C, high internal temperatures may cause thermal limit device
to shut down heater.

KEY

PART

NO.

NUMBER

DESCRIPTION

QTY.

1

099568-01

Inner Shell (Combustion

Chamber)

1

2

M11084-26

Hex Tap Screw,

#10-16 x 3/8"

7

3

099599-02AB

Outer Shell

1

4

M51104-01

Handle

1

5

099230-01

Hex Tap Shoulder

Screw

4

6

M11084-29

Hex Tap Screw,

#10-16 x 3/4"

2

7

M11084-27

Hex Tap Screw,

#10-16 x 1/2"

3

8

102592-01

Nut, M6 x .75

2

9

099727-01

Burner Assembly

1

10

099539-01

Ignitor Electrode

1

11

M11084-38

Hex Tap Screw,

#8-18 x 3/8"

8

12

099537-02

Fan

1

13

100398-02

Motor Assembly (Includes

Rubber Washer and
Fan Nut)

1

14

099540-02

Fan Guard

1

15

097384-02

Captive Washer Nut

3

16

097968-05

Hex Screw, #4-40 x 1/2"

2

17

NPC-00C

Hex Nut, #4-40

2

18

097952-08

Thermal Switch

Assembly

1

19

097776-01

Universal Bushing

1

20

099542-01

Wire Clip

1

21

102607-01

Thermocouple

1

22

099541-01

Valve/Orifice

1

This list contains replaceable parts used in your heater. When ordering parts, be sure
to provide the correct model and serial numbers (from the model plate), then the part
number and description of the desired part.
