78 MFG LEAK_CLASS NRW Simple UNSIGNED8 99
79 MFG VALVE_FLAGS NRW Simple UNSIGNED8 99
80 MFG VALVE_TRIMMAT NRW Simple UNSIGNED8 99
81 MFG VALVE_TRIMCHAR NRW Simple UNSIGNED8 99
82 MFG VALVE_TRIMTYPE NRW Simple UNSIGNED8 99
83 MFG VALVE_TRIMNO NRW Simple UNSIGNED8 99
84 MFG VALVE_SN NRW Simple VISIBLE_STRING “ “
85 MFG STEM_DIAM NRW Simple FLOATING_POINT 0
86 MFG RATED_TRAV NRW Simple FLOATING_POINT 0
87 MFG INLET_PRESS NRW Simple FLOATING_POINT 0
88 MFG OUTLET_PRESS NRW Simple FLOATING_POINT 0
89 MFG ACT_MAN_ID NRW Simple UNSIGNED8 0
90 MFG ACT_FAIL_ACTION NRW Simple UNSIGNED8 0
91 MFG ACT_MODEL_NUM NRW Simple VISIBLE_STRING All “ “
92 MFG ACT_SN NRW Simple VISIBLE_STRING All “ “
93 MFG ACT_TYPE NRW Simple UNSIGNED8 99
94 MFG ACT_SIZE NRW Simple UNSIGNED8 105
95 MFG ACT_AREA NRW Simple FLOATING_POINT 23.8
96 MFG SPRING_TYPE NRW Simple UNSIGNED8 99
97 MFG PO_DATE NRW Simple VISIBLE_STRING “ “
98 MFG INSTALL_DATE NRW Simple VISIBLE_STRING “ “
99 MFG MFG_PHONE NRW Simple VISIBLE_STRING “ “
100 MFG PUR_ORDER_NUM NRW Simple VISIBLE_STRING “ “
101 MFG FINAL_VALUE_RANGE SRW Record SCALE 100.0,0.0,0x53e,1
102 MFG XD_CAL_LOC SRW Simple VISIBLE_STRING “ “
103 MFG XD_CAL_DATE SRW Simple VISIBLE_STRING “ “
104 MFG XD_CAL_WHO SRW Simple VISIBLE_STRING “ “
105 MFG MAIN_RESERVED_3 RW Simple FLOATING_POINT 0
106 MFG MAIN_RESERVED_4 RW Simple FLOATING_POINT 0
107 MFG CONTROL_CONFIG NRW Simple BIT_STRING 0
108 MFG MISC_CONFIG NRW Simple BIT_STRING 0
109 MFG MAIN_BLOCK_TEST R Array UNSIGNED8 0,0,0,0,0,0,0,0
110 MFG MAIN_RESERVED_5 RW Simple FLOATING_POINT 0
111 MFG EXEC_DELAY SRW Simple UNSIGNED16 0
112 MFG MAIN_RESERVED_6 RW Simple FLOATING_POINT 0
113 MFG BLINK_CODE R Simple UNSIGNED8 0
Access Type
NOTE: How the Fieldbus board accesses the respective Control board variable.
• Std - Standard Parameters. These values are constantly updated from the Control Board, except during the ‘Signature’ capture.
• Info - Device Information Parameters. These values are read only at start-up or when any of them are changed. The number -n is used to group
parameters into manageable sizes.
• Diag - Advanced Diagnostic
• Parameters - These values are active only when the parameter ‘Enable diagnostic Variable Access’ is set in TEST_MODE.
Transducer Block Diagram
Figure 8.2 is a block diagram showing the basic components of the transducer block.
