DRAM Configuration
Move the cursor to this field and press , the following screen will appear.
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Phoenix - AwardBIOS CMOS Setup Utility
DRAM Configuration
Item Help
Menu Level

↑↓ : Move PU/PD/+/-: Change Priority F10: Save ESC: Exit

MCT Memory Timing
DCTs Mode
Memory Hole Remapping
Auto Optimize Bottom IO
x Bottom of [31:24] IO Space
Bottom of UMA DRAM [31:24]
Press Enter
Ganged
Enabled
Enabled
C0
FC
MCT Memory Timing
Refer to the following pages for more information on this submenu.
DCTs Mode
The options are Ganged and Unganged.
Memory Hole Remapping
The options are Enabled and Disabled.
Auto Optimize Bottom IO
The options are Enabled and Disabled.
Bottom of [31:24] IO Space
This field is used to enter the memory that will be remapped to another address.
The minimum is 0000 and the maximum is 00FF.
Bottom of UMA DRAM [31:24]
This field is used to enter the UMA DRAM value. The minimum is 0000 and the
maximum is 00FC.
