OnChip SATA Device
OnChip SATA Channel
This field is used to enable or disable the onboard SATA.
RAID Invoke Mode
The options are Auto, Biggest First and Smallest First.
OnChip SATA Type
This field is used to configure the SATA devices supported by the south-
bridge.
Native IDE
This option configures the Serial ATA drives as Parallel ATA storage devices.
RAID
This option allows you to create RAID on Serial ATA devices.
AHCI
This option allows the Serial ATA devices to use AHCI (Advanced Host Con-
troller Interface).
Legacy IDE
This option configures the Serial ATA drives as Legacy IDE storage devices.
Combined Mode
This field is used to enable or disable the combined mode.
PATA Channel Mapping
The options are Primary and Secondary.
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Phoenix - AwardBIOS CMOS Setup Utility
OnChip SATA Device
Item Help
Menu Level

↑↓ : Move PU/PD/+/-: Change Priority F10: Save ESC: Exit
OnChip SATA Channel
RAID INVOKE MODE
OnChip SATA Type
Combined Mode
PATA Channel Mapping
Enabled
AUTO
Native IDE
Enabled
Secondary
The settings on the screen are for reference only. Your version may not be identical to
this one.
