BIOS Setup
Onboard Super IO
Onboard Serial Port 1 and Onboard Serial Port 2
Auto
The system will automatically select an I/O address for the onboard serial
port 1 and serial port 2.
3F8/IRQ4, 2F8/IRQ3, 3E8/IRQ4, 2E8/IRQ3
Allows you to manually select an I/O address for the onboard serial port 1
and serial port 2.
Disabled
Disables the onboard serial port 1 and/or serial port 2.
CIR Port Address
This field is used to select an I/O address for the CIR device.
CIR Port IRQ
This field is used to select an IRQ for the CIR device.
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Phoenix - AwardBIOS CMOS Setup Utility
Onboard Super IO
Item Help
Menu Level

↑↓ : Move PU/PD/+/-: Change Priority F10: Save ESC: Exit
Onboard Serial Port 1
Onboard Serial Port 2
CIR Port Address
x CIR Port IRQ
3F8/IRQ4
2F8/IRQ3
Disabled
11
The settings on the screen are for reference only. Your version may not be identical to
this one.
