13.8 9480, 4284 - Cabling to an AT&T SAC E2A Remote
The 4284 and 9480 are able to accept the E2A protocol on any of its ports. The AT&T
SAC is an E2A remote interface for discrete scan points.
These instructions for the interface to the AT&T SAC E2A Remote substantially differs
from the 4000, 4180, and the 4280. Specifically, a special interface adapter is no longer
required.
The AT&T SAC presents a DB25 Male connector. The adapter used to connect to the
AT&T SAC is the standard asynchronous DCE with a DB25 female.
When a 9480 is used, it is connected directly to the AT&T SAC E2A remote without
special cabling.
The configuration of the port is as follows:
Port type=orig prot=e2a
Port dest=<
E2AHOB IP Address> dport=< E2AHOB TCP Port>
Port dxe=dce swcar=on
Rs
In the example above, the
E2AHOB may be replaced with an IP-E2A application
instance on a 6xxx. Please note that the E2A protocol functionality of this release of the
xxxx requires release 5.1 of IP-E2A or later.
