9 4 8 0 , 4 1 8 0 , 4 2 8 0 , 4 2 8 4 4 0 0 0 X A U s e r M a n u a l
04/09/09
26
4.10 The 9008 RS-530/V.35/RS-422/V.11 Adapter
The 9008 series of adapters are used to provide balanced physical interfaces to the
4000XA, 4180, 4280, and 4284 user ports.
The 9008 supports V.35, V.11, RS-422, and RS-530 interfaces.
The 9008 is available is DCE and DTE variants. It uses an industry standard RJ45 to
connect to the 4180, 4280 and 4284. It provides an industry standard RS-530 DB25
interface for the balanced physical interface. For legacy interfaces that require a
Winchester 34 connection, the Black Box FA059 (DTE), and FA058 (DCE) wiring
adapters may be used.
The picture below depicts a 9008-DTE with the Black Box FA059 Winchester 34 pin
adapter.
