7 S N M P
The xxxx SNMP V1 agent supports a multitude of SNMP MIB variables, SNMP Traps,
and Set and Get operations.
7.1
SNMP Version 1 Commands
Command Operational
Result
Get
Requests the values of one or more Management Information Base (MIB)
variables.
GetNext
Enables MIB variables to be read sequentially, one variable at a time.
Set
Permits one or more MIB values to be updated.
GetResponse
Used to respond to a Get, GetNext, or Set.
Trap
Indicates the occurrence of a predefined condition.
7.2
xxxx SNMP MIB Variable Database
RO = Read-Only Variable
R/W = Read/Write Variable
SIV = Storage is Volatile
MIB Variable
Number
Name MIB
Console
Equivalent Acces
s
Notes
1.3.6.1.2.1.1.1.0 SysDescr
MIB-II
Banner
Message
RO
1.3.6.1.2.1.1.2.0 SysObjectID MIB-II
None
RO
1.3.6.1.2.1.1.3.0 SysUpTime
MIB-II
None
RO
1.3.6.1.2.1.1.4.0 SysContact
MIB-II
None
R/W SIV
1.3.6.1.2.1.1.5.0 SysName
MIB-II
None
R/W SIV
1.3.6.1.2.1.1.6.0 SysLocation
MIB-II
None
R/W SIV
1.3.6.1.2.1.1.7.0 SysServices MIB-II
None
RO
1.3.6.1.2.1.4.1.0 IpForwarding MIB-II
None
RO
1.3.6.1.2.1.4.2.0 IpDefaultTTL MIB-II
None
RO
1.3.6.1.2.1.4.3.0
IpInReceives
MIB-II Number of Ethernet Pkts Rcvd
RO
1.3.6.1.2.1.4.4.0
IpInHdrErrors
MIB-II Nbr of Packets w/Header Errs
RO
1.3.6.1.2.1.4.5.0
IpInAddrErrors
MIB-II Nbr Rx Packets w/Wrong Addr
RO
1.3.6.1.2.1.4.6.0 IpForwDatagrams
MIB-II
None
RO
1.3.6.1.2.1.4.7.0 IpInUnknownProt
os
MIB-II Nbr of Packets w/Unk Protocol
RO
1.3.6.1.2.1.4.8.0
IpInDiscards
MIB-II Nbr of Packets Disc due to
Resource
RO
1.3.6.1.2.1.4.9.0
IpInDelivers
MIB-II Inferred from DMEAS counters
RO
1.3.6.1.2.1.4.10.0
IpOutRequests
MIB-II Number of Device Frames
Transmitted
RO
1.3.6.1.2.1.4.11.0
IpOutDiscards
MIB-II Nbr of Port frames Disc due to
Resource
RO
1.3.6.1.2.1.4.12.0 IpOutNoRoutes MIB-II
None
RO
1.3.6.1.2.1.4.13.0 IpReasmTimeout
MIB-II
None
RO
