9 4 8 0 , 4 1 8 0 , 4 2 8 0 , 4 2 8 4 4 0 0 0 X A U s e r M a n u a l
04/09/09
22
4.7 DATA TRANSPORT CABLING
.
4.7.1 User Ports
Although the 4000XA, 4180, 4280, and 4284 are each configured to work like a SAM16,
the pin outs on the RJ45 connectors used for the RS-232 user ports are identical to the
pin outs for the SAM64 and SAM504 user ports. Thus, all adapters and cables used with
these SAM types will apply to the unit. Refer to the Cabling section of Data Networking
Products Synchronous/Asynchronous Multiplexer Reference. In most cases, a standard
RJ45-terminated Category 5 twisted-pair data cable can be used, with the appropriate
adapter (depending on the gender) on the connector on the endpoint device.
4.8 Ordering Information
Cable or
Adapter
Description Order
Information
(Lucent)
Order
Information
(Reseller)
V.35(M) to
DB25(F) 34-pin-M
25-pin-F 408418911 V.35(M) to
DB25(F)
D8AG-F 25-pin-F
mod socket, null modem wiring ED5P055-31 G-
138
D8AG-F
D8AH-F 25-pin-F
mod socket ED5P055-31 G-
147 D8AH-F
D8W Mod plug
Mod plug, straight through, 3ft.
408421803 D8W
SYNC DCE-F 25-pin-F
mod socket ED5P055-31 G-
150 SYNC DCE-F
SYNC DTE-F 25-pin-F
mod socket ED5P055-31 G-
151 SYNC DTE-F
