The second generation Digital CAT5 transmitter User 's Manual 1
Chapter 1 Summary
The second generation uCAT5 series digital
transmitter is a new generation twisted-pair
transmitter upgrading the first generation product.
It transmits integrated CAT5 audio, video, control
signals. By increasing the transmission end
monitoring output interface, it can monitor the
video input state and backup output. Adopting the
advanced HDBaseT technology, based on single
CAT5e/6
shielding cable, its maximum
transmission distance is up to 100M.
Focus on the market application and current
video interfaces, CR-uCAT5 AV 200T transmitter
integrates Video, S-video, YPbPr (YCbCr), VGA
(RGBHV) into a unified DB15 (VGA Female
socket) interface input and HDMI, DVI input.
Together with one analog audio input (except
HDMI input mode), it can directly select
corresponding input signal source through the
channel selecting button the serial command. Any
video input of Video, S-video, YPbPr, VGA, DVI
can simultaneously transmit analog audio input
and directly output HDMI signal by HDMI
monitoring
interface. Support color space
conversion, eliminate flicker, support noise
reduction and scaling, resolution can be upscale
to 1080P.
The second generation uCAT5 series transmitter
is increased with the sending end video
surveillance function. It can monitor the output
state of receiving end in real-time, so as to meet
the different application needs of users. It can be
widely used in fields like network flat panel
display and large screen splicing wall display,
advertising project, industrial automation control,
medical
equipment, security monitoring,
multimedia teaching etc.
1.1 Classification of Digital
CAT5 Transmitter
1.1.1 Digital uCAT5 transmitter
AV digital video twisted pair transmitter
CR-uCAT5 AV 200T
DVI digital video twisted pair transmitter
CR-uCAT5 DVI 200T
CR-uCAT5 DVI 200R
HDMI digital video twisted pair transmitter
CR-uCAT5 HDMI 200T
CR-uCAT5 HDMI 200R
VGA video twisted-pair receiver
CR-uCAT5 VGA 200R
3 types of transmitters and 3 types of receivers
can be in any arbitrary combinations.
1.1.2 Accessories
 Infrared transmitter CR-IR/T.
 Infrared receiver CR-IR/R.
 3.5mm headphones socket to DB9 male
socket.
 3.5mm headphones socket to DB9 female
socket.
 DB15 male socket transfer line (S terminal,
RCA head.
