The second generation Digital CAT5 transmitter User 's Manual

9

HDMI interface for connecting input / output
devices with HDMI interface, such as PC
computer, Blu-ray DVD, monitor, LCD TV, etc.

RS-232——RS-232 control port

Using DB9 to 3.5MM earphone socket, for the
remote control, can be connected with PC. The
sending end with 3.5MM to DB9 female socket,
receiver with 3.5MM to DB9 male socket, both
ends are set to a consistent baud rate, ranging
from 110bps to 115200bps.

IR TX——Infrared transmitting port

3.5MM earphone socket infrared transmitter is
adopted.

IR RX -- Infrared receiving port

3.5MM earphone socket infrared transmitter is
adopted.

DC 12V -- Power input port

Support DC 12V input and side with a power
indicator.

HDBaseT—CAT5e/6 network transmission

interface
Uses

RJ45

interface

for

long

distance

transmission of HDBaseT signals.

MONITOR—Video

monitoring

output

interface
It can monitor HDMI signals of the input end.

AUDIO——Audio signal input / output port

Provides one-way non-equilibrium, stereo audio
input and output port and connects to PC and
other peripheral equipments.
