CREATOR CHINA 2013-08 WWW.CREATOR1997.COM

The second generation Digital CAT5 transmitter User 's Manual

17

Model

Parameters

CR-uCAT5 DVI 200R Receiver

Signal type

DVI1.0 / T.M.D.S. full digital signal

Interface

DVI-D Interface

Signal strength

T.M.D.S. +/- 0.4Vpp

Minimum / maximum
level

T.M.D.S. 2.9V/3.3V

Impedance

Differential100Ω

Control interface
Serial port control

RS232 (3.5MM earphone socket)

Baud rate:

110-115200bps

Infrared control

IR (3.5MM earphone socket)

IR frequency

38K

Audio output

1 analog stereo input,3.5MM earphone socket

Frequency response

20Hz——20KHz ±0.05db

Input level

2Vrms(maximum)

Maximum

output

distance

of

video

cable

Less than 7m,when the resolution is 1920x1080P@60(recommended to use
certified HDMI cable,such as Molex TM cable)

HDBaseT

Input

Interface
Interface

High speed RJ45

Transmission
distance

Up to 100m via CAT5e/6 shielding cable

Power supply

12V/1.5A DC adapter

Maximum

power

dissipation

8.5W

2.7.4 CR-uCAT5 HDMI 200T Technical Parameters

Model

Parameters

CR-uCAT5 HDMI 200Ttransmitter

HDMI video input
Supported protocol

HDMI1.3a, HDCP1.3,EDID1.4

Bandwidth

Pixel Bandwidth165MHz , full digital

Interface bandwidth

6.75Gbps

The

maximum

supported resolution

Normal PC: 1600x1200@60Hz
HDPC: 1900x1200@60Hz
HDTV: 1920x1080P@60Hz

Maximum

output

distance

of

video

cable

Less than 7m,when the resolution is 1920x1080P@60(recommended to use
certified HDMI cable,such as Molex TM cable)

Signal type

HDMI 1.3a / T.M.D.S. full digital signal

Interface

HDMI-A Interface
