The second generation Digital CAT5 transmitter User 's Manual
20
Model
Parameters
CR-uCAT5 VGA 200R Transmitter
Gain
0dB
Frequency response
20Hz~20KHz
Total
harmonic
distortion + noise
0.01%@1kHz( under constant voltage)
S/N ratio(S/N)
>80dB at Vin=0V
CMRR
>75dB @:20 Hz~20 kHz
Signal type
Stereo (unbalanced connection)
Impedance
Input:>10kΩ(balanced or unbalanced connection)
Output:50Ω(unbalanced connection)
Maximum input level
+19.5dBu, (balanced or unbalanced connection)
Gain error
±0.1dB @20 Hz~20 kHz
Port control
Serial port control
RS-232(3.5MM earphone socket)
Baud rate
110-115200bps
Infrared control
Infrared control
IR(3.5MM earphone socket)
IR frequency
38KHz
HDBaseT input interface
Interface
High speed RJ45
Transmission
distance
Up to 100m via CAT5e/6 shielding cable
Specification
Power supply
12V/1.5A DC adapter
Maximum
power
dissipation
11.5W
CR-uCAT5 VGA 200R receiver supports any resolution of the transmitter output. In order to achieve
the best display effect, we suggest set its resolution the same as the recommended resolution of the
terminal display device. If it is used together with CR-uCAT5 AV 200T transmitter, user can adjust the
output resolution of transmitter. With HDMI,DVI transmitter, user can directly regulate the output
resolution of the source.
2.7.7 CR-uCAT5 AV 200T Transmitter Engineering Serial Instruction Sets
Model
Parameters
CR-uCAT5 AV 200T Transmitter
Serial protocol:Baud rate:9600
Data bits:8 Stop bit:1 Parity:no
Instructions
Function description
Video Switch Command:
01$01!
CV video switch out
02$01!
YC video switch out
03$01!
YUV video switch out
