The second generation Digital CAT5 transmitter User 's Manual

15

Model

Parameters

CR-uCAT5 AV 200T Transmitter

HDMI monitoring output port
Supported protocol

HDMI1.3a, HDCP1.3,EDID1.4

Bandwidth

Pixel bandwidth165MHz , full digital

Interface bandwidth

6.75Gbps

The maximum
supported resolution

Normal PC: 1600x1200@60Hz HDPC: 1900x1200@60Hz
HDTV: 1920x1080P@60Hz

Signal type

HDMI 1.3a / T.M.D.S. full digital signal

Interface

HDMI-A Interface

Signal strength

T.M.D.S. +/- 0.4Vpp

Minimum / maximum
level

T.M.D.S. 2.9V/3.3V

Impedance

Differential100Ω

Supported resolution

800X600@60Hz;1024X768@60Hz;1280X720@60Hz;1280X800@60Hz;128
0X960@60Hz;1280X1024@60Hz;1366X768@60Hz;1440X900@60Hz;1600
X900@60Hz;1920X1080@60Hz;

Maximum

output

distance

of

video

cable

Less than 7m,when the resolution is 1920X1080P@60 (recommended to use
certified HDMI cable,such as Molex TM cable)

HDBaseT output port
Interface

High speed RJ45

Transmission
distance

Up to 100m via CAT5e/6 shielding cable

Power supply

DC 12V/1.5A

Maximum

power

dissipation

11.5W

2.7.2 CR-uCAT5 DVI 200T Technical Parameters

Model

Parameters

CR-uCAT5 DVI 200T transmitter

DVI VIDEO INPUT
Supported protocol

DVI1.0, EDID1.4

Bandwidth

Pixel Bandwidth165MHz , full digital

Interface bandwidth

6.75Gbps

The

maximum

Supported resolution

Normal PC: 1600x1200@60Hz HDPC: 1900x1200@60Hz
HDTV: 1920x1080P@60Hz

Signal type

DVI1.0 / T.M.D.S. full digital signal

Interface

DVI-D Interface

Signal strength

T.M.D.S. +/- 0.4Vpp

Minimum / maximum
level

T.M.D.S. 2.9V/3.3V

Impedance

Differential100Ω
