The second generation Digital CAT5 transmitter User 's Manual 18
Model
Parameters
CR-uCAT5 HDMI 200Ttransmitter
Signal strength T.M.D.S. +/- 0.4Vpp
Minimum / maximum
level
T.M.D.S. 2.9V/3.3V
Impedance Differential100Ω
Audio input HDMI embedded digital audio
Control interface
Serial port control
RS232(3.5MM earphone socket)
Baud rate 110-115200bps
Infrared control IR (3.5MM earphone socket)
IR frequency 38K
HDMI monitoring output interface
Supported protocol
HDMI1.3a, HDCP1.3,EDID1.4
Bandwidth Pixel Bandwidth165MHz , full digital
Interface bandwidth 6.75Gbps
The maximum
supported resolution
Normal PC: 1600x1200@60Hz HDPC: 1900x1200@60Hz
HDTV: 1920x1080P@60Hz
Signal type HDMI 1.3a / T.M.D.S. full digital signal
Interface HDMI-A Interface
Signal strength T.M.D.S. +/- 0.4Vpp
Minimum / maximum
level
T.M.D.S. 2.9V/3.3V
Impedance Differential100Ω
Maximum output
distance of video
cable
Less than 7 m, when the resolution is 1920x1080P@60 (recommended the
use of certified HDMI cable, as Molex TM cable)
HDBaseT output
interface
Interface High speed RJ45
Transmission
distance
Up to 100m via CAT5e/6 shielding cable
Power supply DC 12V/1.5A
Maximum power
dissipation
7.5W
2.7.5 CR-uCAT5 HDMI 200R Technical Parameters
Model
Parameters
CR-uCAT5 HDMI 200R Receiver
HDMI video output
Supported protocol
HDMI1.3a, HDCP1.3,EDID1.4
Bandwidth Pixel Bandwidth165MHz , full digital
Interface bandwidth 6.75Gbps
