The second generation Digital CAT5 transmitter User 's Manual

14

Model

Parameters

CR-uCAT5 AV 200T Transmitter

Supported video input
format

480i/NTSC;480P/NTSC;576i/PAL;576P/PAL

YC analog video input
Format

NTSC,PAL,SECAM

Signal type

S-VIDEO

Interface

DB15 male to S terminal (custom line)

Signal strength

1VPP(standard),0.7VPP-1.6VPP

Minimum / maximum
level

0.7VPP-1.6VPP

Impedance

75Ω

Supported

video

input format

480i/NTSC;480P/NTSC;576i/PAL;576P/PAL

YUV analog video input
Format

NTSC,PAL,SECAM

Signal type

Component video(YPbPr/YCbCr)

Interface

Interface DB15 male to RCA female head (custom line)

Supported

video

input format

480i/NTSC;480P/NTSC;576i/PAL;576P/PAL;720P/NTSC;1080i/PAL

Signal strength

1V p-p :(Y in component video) 0.3Vp-p: (PbPr/CbCr in component video)

Minimum / maximum
level

Analog signal: -2V/+2V

Impedance

75Ω

VGA analog video input
Signal type

RGBHV

Interface

DB15 female Interface

Impedance

75Ω

Supported

input

resolution

640x480@60Hz;800x600@60Hz;1024x768@60Hz;1280x720@60Hz;1280x7
68@60Hz;1280x960@60Hz;1280x1024@60Hz;1400x1050@60Hz;1440x90
0@60Hz;1600x1200@60Hz;1920x1080@60Hz;1920x1200@60Hz;

VGA horizontal and vertical synchronous signal input
Input level

4.0V-5.0V p-p

Output Impedance

75Ω

Control interface
Serial port control

RS232 (3.5MM earphone socket)

Baud rate

110-115200bps

Infrared control

IR

(3.5MM earphone socket)

IR frequency

38K

Audio input

1 analog stereo input,3.5MM earphone socket

Frequency response

20Hz——20KHz ±0.05db

Audio input level

2Vrms(1 analog stereo input)
