CREATOR CHINA 2013-08 WWW.CREATOR1997.COM

The second generation Digital CAT5 transmitter User 's Manual

21

04$01!

VGA video switch out

05$01!

DVI video switch out

06$01!

HDMI video switch out

Audio Volume Command:
XX$52!

Volume(00<=xx<=70)

01$53!

MUTE ON

02$53!

MUTE OFF

Video Output Command:
01$03!

800x600@60Hz

02$03!

1024x768@60Hz

03$03!

1280x720@60Hz

04$03!

1280x800@60Hz

05$03!

1280x960@60Hz

06$03!

1280x1024@60Hz

07$03!

1366x768@60Hz

08$03!

1440x900@60Hz

09$03!

1600x900@60Hz

10$03!

1920x1080@60Hz

11$03!

1360x768@60Hz

Reserved for future use

12$03!

1600x1200@60Hz

Reserved for future use

13$03!

1920x1200@60Hz

Reserved for future use

OSD Command:
01$04!

Enter menu

02$04!

Exit menu

03$04!

Select menu options to the left

04$04!

Select menu options to the right

05$04!

Select menu options upwards

06$04!

Select menu options downwards

07$04!

Confirm menu option

01$05!

Restore factory settings

1. The function of reserving resolution for future use only supports serial instruction selection,

cannot be selected by DIP

2. The function of reserving resolution for future use needs monitor’s support. If it does not support,

may lead to abnormal screen display.

Model

Parameters

CR-uCAT5 AV 200T Transmitter

XX$12!

Adjust brightness(00<=XX<=99)

XX$13!

Adjust contrast(00<=XX<=99)

XX$14!

Adjust saturation(00<=XX<=99)

The VGA input is invalid

XX$15!

Adjust sharpness(00<=XX<=24)

The VGA input is invalid

XX$16!

Adjust hue(00<=XX<=99)

The VGA input is invalid
