Chapter 3 Accessories
3.1 Infrared Transmitter
CR-IR/T
The infrared transmitter CR-IR / T is used to
transmit infrared signals to the infrared receiver,
infrared emission frequency ranging from 20 KHz
to 100KHz.
CR-IR/T Dimensions:
3.2 Infrared Receiver CR-IR/R
Infrared receiver CR-IR / R is for receiving
the infrared signal to the infrared device, infrared
receiver frequency is38KHz.
CR-IR/R Dimensions:
3.3 3.5mm Headset Connector
to DB9 Male Socket Connecting
Line
3.4 3.5mm Headset Connector
to DB9 Female Socket
Connecting Line
3.5 DB15 Male Socket to RCA
Terminal, SV Terminal
Connection Line (VGA to CV
video, Y/C video, YPbPr video)
