Comtech EF Data MBT-4000B - Manual (Page 61)

Multi-Band Transceiver System Revision 0
Remote Command MN/MBT4000B.IOM
A-25
Parameter
Type
Command
(Instruction
Code and
qualifier)
Valid on
MBT,
BDC, or
BUC
Arguments for
Command or
Response to
Query
Description of arguments
(Note that all arguments are ASCII numeric codes, that is,
ASCII codes
between 48 and 57)
Response to
Command
(target to controller)
Query
(Instruction
Code and
qualifier)
Response to
query
(target to
controller)
Retrieve
Maintenance Status
N/A All MBT-4000B -
103 bytes,
alphanumeric
BDC –
98 bytes,
alphanumeric
BUC –
98 bytes,
alphanumeric
Query only.
Used to Query the maintenance status of the unit.
Example for MBT-4000B base: <0001/RMS?{cr}
>0001/RMS={cr}{lf}
15VT1=015.1{cr}
7V5T1=007.7{cr}
5VLT1=005.0{cr}
28VT1=027.2{cr}
REFVT=001.3{cr}
LNA_1=000.0{cr}
LNA_2=000.0{cr}
RFSWP=B{cr}
IFSWP=N{cr}
RRFSW=B{cr}
RIFSW=B{cr}{lf}
Example for BUC: <0001A2/RMS={cr}
>0001A2/RMS={cr}{lf}
15VT=015.1{cr}
7V5T=007.6{cr}
5VLT=005.2{cr}
REFV=XXX.X{cr} (reserved for future use)
SYNT=007.2{cr}
POUT=XXX.X{cr} (reserved for future use)
TEMP=+25.0{cr}{lf}
Example for BDC: <0001A1/RMS={cr}
>0001A1/RMS={cr}{lf}
15VT=015.1{cr}
7V5T=007.6{cr}
5VLT=005.2{cr}
REFV=XXX.X{cr} (reserved for future use)
SYNT=007.2{cr}
LNAC=255.0{cr}
TEMP=+25.0{cr}{lf}
Note: “REFV” will show tuning voltage of reference OSC for
standalone. Otherwise REFV=xxx.x which means Not Applicable. N/A RMS? RMS=x….x
(see description
for details of
arguments)
