Multi-Band Transceiver System Revision 0
Remote Command MN/MBT4000B.IOM
A-12
Parameter
Type
Command
(Instruction
Code and
qualifier)
Valid on
MBT,
BDC, or
BUC
Arguments for
Command or
Response to
Query
Description of arguments
(Note that all arguments are ASCII numeric codes, that is,
ASCII codes between 48 and 57)
Response to
Command
(target to
controller)
Query
(Instruction
Code and
qualifier)
Response to
query
(target to
controller)
Concise
Configuration
Status
N/A All 48 bytes (BDC)
41 bytes (BUC)
32 bytes (MBT)
alphanumeric Query only. Returns the summarized version of RCS.
Example for MBT-04000 base unit:
<0001/CCS?{cr}
>0001/CCS=aa,bb,cc,dd,e,ff,g,h{cr}{lf}
Where:
aa=Frequency band for Unit 1 BXC (‘C”, ‘X”, ‘Ka’, ‘Ku’, or ‘NA’)
bb=NA
cc=Direction for Unit 1 BXC (‘DN’=BDC, ‘UP’=BUC, ‘NA’=None)
dd=NA
e=Redundancy mode (0, 1, or 2)
ff=Automatic mode
g=Redundancy loop cable address
N=No Cable
A=MBT-A
B=MBT-B
h=External reference lock (1=locked, 0=Not locked)
Example BDC or BUC:
<0001A1/CCS?{cr}{lf}
>0001A1/CCS=aaaaa,bb.bb,c,d.d,e,ff,g,hhhh
,i,j,{CR}{lf}
Where:
aaaaa=Frequency in MHz
bb.bb=Attenuation in dB
c=mute state, 0=unmated, 1=muted
d.d=slope adjust
e=LNA current source (BDC only, BUC=X)
ff=LNA current window (BDC only, BUC=XX)
g=LNA fault logic (BDC only, BUC=X)
hhhh=XXXX (reserved for future use)
i=X (reserved for future use)
j=Fault recovery, 0=Manual, 1=Auto
N/A CCS? CCS=x….x
(see
description for
details of
arguments)
