Comtech EF Data MBT-4000B - Manual (Page 23)

Multi-Band Transceiver System Revision 0
Installation MN/MBT4000B.IOM
2-5
2.2.5 RF S
WITCH
(J10) P
IN
C
ONNECTIONS
Table 2-6. RF Switch (J10) Pin Connections
Pin RF SWITCH (J10)
A POS 1 RF
B GND
C
POS 2 RF
D POS 1 IND RF
E GND
F
POS 2 IND RF
Mating Connectors:
MS3116J10-6P
CN/MS3116J10-6P
