Multi-Band Transceiver System Revision 0
System Operation MN/MBT4000B.IOM
3-2
3.2 B
LOCK
U
P
C
ONVERTER
(BUC-4000)
The BUC-4000 translates an L-Band carrier to the desired output frequency (C, X-, or
Ku- or Ka-), with an output level capable of driving an HPA.
BUC-4000 C, X, Ku, Ka
Band Frequency LO Frequency Inverting
C-Band 5850 to 6650 MHz 4900 MHz No
X-Band 7900 to 8400 MHz 6950 MHz No
Ku-Band-W 13.75 to 14.50 GHz 12.800 GHz No
Ka-Band 30.00 to 31.00 GHz
Notes:
1. No spectral inversion
2. 10 dB gain adjustment.
