Multi-Band Transceiver System

Revision 0

Introduction

MN/MBT4000B.IOM

1-3

1.3 S

PECIFICATIONS

1.3.1 S

UMMARY OF

S

PECIFICATIONS

BUC-4000 ODU
Characteristics

Specifications

BUC-4000 ODU
Characteristics

Specification

Input Frequency Range

950–2000 MHz, 125 kHz steps
(1 kHz optional)

Environmental:

Output Freq By Model:

BUC-4000C
BUC-4000X
BUC-4000Ku
BUC-4000Ka


5850-6650 MHz
7900-8400 MHz
13.75-14.50 GHz
30.00-31.00 GHz
27.50-28.50 GHz (optional)
28.50-29.50 GHz (optional)
29.50-30.10 GHz (optional)

Operating

Temperature

ODU: BUC-4000

-40

° to +50° C

(-40

° to 122°F)

Input/Output Impedance 50

Ω

Operating

Altitude

10,000 feet above sea level

Input Return Loss

15 dB minimum

Operating Humidity

5 to 95%, non-condensing

Output Return Loss

18 dB minimum

Non-Operating

Temperature

-50

° to + 75°C

(58

° to +160°F)

Input Connector

Type ‘N’ – Female

Physical:

Output Connector

Type ‘N’ – Female (C, X, and Ku)

ODU: MBT-4000B

Gain

15 dB nominal at minimum
attenuation

Prime Power

90 to 260 VAC, 47 to 63 Hz

User Attenuation Range 0 to 10 dB

Size

Refer to Figure 1-3.

Output Power, P1dB

+10 dBm minimum

Third Order Intercept

+20 dBm minimum

Carrier Spurious

-60 dBc

Non-Carrier Spurious

-60 dBm

External Reference

Input, either 5 to 10 MHz

±5 dBm

optional
