Comtech EF Data MBT-4000B - Manual (Page 21)

Multi-Band Transceiver System Revision 0
Installation MN/MBT4000B.IOM
2-3
2.2.2 IF S
WITCH
(J4) P
IN
C
ONNECTIONS
Table 2-3. IF Switch (J4) Pin Connections
Pin IF Switch (J4)
A POS 1 IF
B GND
C
POS 2 IF
D POS 1 IND IF
E GND
F
POS 2 IND IF
Mating Connectors:
Cannon MS3116J10-6P
CEFD CN/MS3116J10-6P
2.2.3 R
EDUNDANT
L
OOP
(J7) P
IN
C
ONNECTIONS
Table 2-4. Redundant Loop (J7) Pin Connections
Pin Redundant Loop (J7)
A SW POS 2 DRIVE OUT
B GND
C
SW POS 2 DRIVE OUT
D RF SW IND OUT
E IF SW IND OUT
F SW POS 1 DRIVE IN
G SW POS 2 DRIVE IN
H RF SW IND IN
J IF SW IND IN
K MBT A IND
L MBT B IND
M NC
N
BXC 1 FLT OUT
P BXC 2 FLT OUT
R BXC 1 FLT IN
S BXC 2 FLT IN
T NC
U TX
V RX
Mating
Connectors:
CEFD CA/WR11224 Redundant Loop Cable
