Multi-Band Transceiver System Revision 0
System Operation MN/MBT4000B.IOM
3-4
3.3.2 K
U
-B
AND
Table 3-2. For Ku-Band: LO and MIX Information for Demodulator and LNB, Ku-Band
LNB Part No. Description
LO (Offset)
Frequency
(MHz)
MIX
(+/-)
Min
LNB
Satellite
Frequency
(MHz)
Max
LNB
Satellite
Frequency
(MHz)
L-Band
Frequency
At
LNB Min
(MHz)
L-Band
Frequency
At
LNB Max
(MHz)
Demod
Spectrum
(Utility
Demod
Menu)
Operating
Voltage, V
RF
Connector
RF/LNB-10.9-11.7FE 10.95 – 11.7 GHz
Ext Ref
10,000.00 + 10,950.00 11,700.00 950.00 1700.00 Normal 18 Type F
RF/LNB-11.7-12.2FE 11.7 – 12.2 GHz
Ext Ref
10,750.00 + 11,700.00 12,200.00 950.00 1450.00 Normal 18 Type F
RF/LNB-12.2-12.7FE 12.25 - 12.75 GHz
Ext Ref
11,300.00 + 12,250.00 12,750.00 950.00 1450.00 Normal 18 Type F
RF/LNB-10.9-11.7F03 10.95 – 11.7 GHz
± 3 ppm
10,000.00 + 11,200.00 11,700.00 950.00 1450.00 Normal 18 Type F
RF/LNB-11.7-12.2F03 11.7 – 12.2 GHz
± 3 ppm
10,750.00 + 10,950.00 11,700.00 950.00 1700.00 Normal 18 Type F
RF/LNB-12.2-12.7F03 12.25 - 12.75 GHz
± 3 ppm
11,300.00 + 12,250.00 12,750.00 950.00 1450.00 Normal 18 Type F
