turboIP-45 Performance Enhancement Proxy Revision 0
SNMP CD/TURBOIP45.IOM
5–15
Leaf turbo IP45CompressionRatio
Type Integer
ACCESS:
GET = RO
GET/SET = RW
RC =
READ/CREATE
RO
Description The average, since last statistic reset, over all data passing from the LAN to WAN
interfaces over all compressed accelerated sessions,of the ratio of the payload size of
the transmitted segments to the size that the payloads would have if the data were
not compressed.
OID 1.3.6.1.4.1.6247.23.1.5.2.2
Leaf turbo IP45ResetCompressionRatio
Type Integer
ACCESS:
GET = RO
GET/SET = RW
RC =
READ/CREATE
RW
Description Allows reset of the average compression ratio.
5.10 turboIP-45™ Admin
OID 1.3.6.1.4.1.6247.23.1.6.1
Leaf turboIP45AdminFunctions
Type N/A
ACCESS:
GET = RO
GET/SET = RW
RC = READ/CREATE
N/A
Description
OID 1.3.6.1.4.1.6247.23.1.6.1.1
Leaf turboIP45SystemDateAndTime
Type DateAndTime
ACCESS:
GET = RO
RO
